LINE FILLING PUMPS

Horizontal Centrifugal Axial Split Casing Pump consisting of 50 Models with five Shaft groups fro minimum inventory of spares and with nominal impeller diameters of 300mm to 790mm.
The pumps are also designed in two stage to meet the high head requirement. Pumps are available in both direction to drive with electric motor and diesel engine. Add to Special Features:
“Lubrication” – Available in both grease and oil lubrication (fitted with bearing isolator)

cnc-image

Operation Range

  • Capacity: 10 TO 5000M3/HR
  • Total head: 350 METERS
  • Size: 50 TO 600 MM
  • Pressure: UP TO 40KG/CM
  • REC. SPEED: 750 TO 3000 R.P.M.
  • REC. POWER: UP TO 1500KW

Available Construction

  • C.I. - IS:210 GR. FG 200/260
  • CAST STEEL-ASTM-A216, GR. WCB
  • BRONZE - IS:318 GR. LTB II/ Phosphorus bronze
  • STAINLESS STEEL - ASTM-A743, CF8/CF8M
  • ALLOY20 - ASTM-A743, CN7
  • HESTALLOY 'B' & 'C'
  • MONEL
  • CD4MCU

APPLICATION

  • BOOSTING WATER
  • CONDENSER & CHILLED WATER CIRCULATION
  • FIRE FIGHTING
  • IRRIGATION
  • MINE WATER
  • RAW WATER
  • SERVICE WATER
  • WHITE WATER
